Paneltim antislip panels

Paneltim antislip panels can bear heavy loads and are suitable for anti-slip floors in many applications.

The panel can be processed using regular technic to make plastic constructions: butt welding, extrusion welding or hot air welding. The short welding cycle considerably improves overall processing time.

The panels being manufactured in prime polypropylene or polyethyleen, joining with solid panels, tubes, etc is possible.

Request Quote
  • Check Mark Delivered across India
  • Check Mark Operator training offered
  • Check Mark 1 Year Warranty
  • Check Mark Call +91 9003096815 for Queries
    Guaranteed Safe And Secure Delivery

    Paneltim antislip panels can bear heavy loads and are suitable for anti-slip floors in many applications.

    Antislip structure

    • Five bar
    • Studs
    • Orange skin

    Thickness

    50 mm (2″)

    Wall thickness

    • Five bar: 3.3 mm (0.13″)
    • Studs: 3.3 mm (0.13″)
    • Orange skin: 3.3 mm (0.13″)

    Materials

    • PP COPO
    • HDPE*

    Internal structure

    50 mm x 50 mm (2×2″)

    Standard dimensions

    1200 mm x 1000 mm x 50 mm (102.36″ x 39.37″ x 1.97″) (L x W x H)

    Weight

    Five bar
    • PP: ± 12 kg/m² (2.5 lb/ft²)
    • HDPE*: ± 13 kg/m² (2.7 lb/ft²)

    Studs
    • PP: ± 12 kg/m² (2.5 lb/ft²)
    • HDPE*: 13 kg/m² (2.7 lb/ft²)

    Orange skin
    • PP: ± 11 kg/m² (2.2 lb/ft²)

    Outside edge

    Distance from antiskid profile to edge: 40 mm (1.57″)
    Orange skin: no outside edge

    Double rib

    The antislip panels have double rib in the middle (cross). This facilitates production of 40 cm, 50 cm and 60 cm (15.75″, 19.69″ and 23.62″) high panels.

    Colours (US:Colors)

    PP prime: UV beige (RAL 7032)
    PP recycled: Black
    PE* prime: UV white (RAL 9010), black
    Other colours (colors) possible on request.
    Paneltim advises against using dark colours (colors) for outside use.

    Open half panels

    On specific request half panels with antiskid profile can be offered. These open half panels have a thickness of 27 mm (1.06″), a checker plate or studs profile on the one side, and an open rib structure on the other side.

    Flexible

    The antiskid profiles always have a double rib (cross) in the middle. This facilitates the production of antiskid panels of 40 cm, 50 cm and 60 cm (15.75″, 19.69″ and 23.62″).

    No internal accumulation of dirt

    The internal cell structure ensures that the panels are always closed all around, even when cutting to size, avoiding ingression of dirt or moisture into the panels.

    Processing

    The panel can be processed using regular technic to make plastic constructions: butt welding, extrusion welding or hot air welding. The short welding cycle considerably improves overall processing time.

    The panels being manufactured in prime polypropylene or polyethyleen, joining with solid panels, tubes, etc is possible.
